Bursting Strength Single Head Clamp N Print Model

Bursting Strength is a widely used measure of resistance to rupture of various materials. A test specimen is held between two circular clamps and subjected to an increasing pressure from a rubber diaphragm. The rubber diaphragm is expanded by a controlled hydraulic pressure until the test specimen ruptures. The Bursting Strength of the specimen is the pressure reading at the time of rupture.

Features:

• Single head machine testing for Paper OR Corrugated Board
• Paper Tester: Fitted with thin Rubber Diaphragm to accurately test materials having lower burst values like Paper.
• Capacity: 14 kg/cm2 with least Count 0.01 kg/cm2.
• Board Tester: Fitted with Moulded Rubber Diaphragm to test material with higher burst values like Paperboard, Corrugated Board, Fabric Cloth, etc. Capacity: 35 kg/cm2 with least Count 0.1 kg/cm2.
• Measuring Units: kg/cm2 or PSI.
• Auto Calibration in 5 simple steps.
• Overload protection.
• Fully enclosed body, panel mounted micro processor based digital display
• Adjustable clamping pressure
• System BF calculation for Paper.
• A group of 12 test can be performed for report.
• Accept or reject validation,.
• Manual clamping
• Average of test results on report.
• Programmable Product Codes, Vender / Customer Codes, GSM, Date & Time.
• Report is directly printed from the built-in Thermal printer.
